Legend / How to useQuick guide + shortcutsHide
🧱 Room
Drag to create a room. Rooms cannot overlap; choose type and floor finish from the panel.
🧱 Wall
Drag to draw an interior wall segment (auto axis-aligned). Doors snap to any wall; windows snap to exterior walls only.
🚪 / 🪟 Doors & windows
Click to place. Switch to Select to drag along a wall. Doors support Flip swing / hinge in the Inspector.
🖱️ Select
Click an element to inspect it. Drag rooms to move them with snapping and no-overlap protection. Drag doors and windows to reposition them.
🧭 Pan / Zoom
Use the Pan tool to move the view. Use the mouse wheel to zoom. The plus/minus buttons work too.
⚙️ Snapping & multi-place
Grid snap is ON. Wall/room snap is ON. Hold ALT to temporarily disable snapping. Hold SHIFT while moving a room to constrain the axis. Multi-place is currently ON.
ALTDisable snapping while dragging
SHIFTConstrain axis while moving rooms
ESCRelease canvas capture (click the canvas to capture again)
VSelect tool
RRoom tool
WWall tool
DDoor tool
NWindow tool
PPan tool
Plan
Units: meters · Grid: 0.1 m · Snap: ON / ON (ALT disables)
Canvas controls active — press Esc to release
